WiFi Gas & CO Alarm Box is a 2-in-1 smart device that detects the gas & carbon monoxide concentration in the kitchen in real time. The gas concentration value can be viewed in real time through the Tuya APP. If the concentration exceeds the standard, an 80-decibel high-pitched alarm will be triggered, and the Tuya smart gas valve will be closed at the same time and an alarm message will be sent to the user.

Packing list：

Gas&CO Alarm Box X1

Instruction for use X1

USB power supply cord X1

Product parameter

Working temperature -20-85°C

Working voltage 5V

Working current 10-496ma

size 100*100*35 mm

The power supply mode USB 5V/1A

Communication protocol WIFI 2.4GHZ / ZIGBEE

color White

Shell material ABS

The weight of the 100g

CO(carbon monoxide) range 0-500ppm

Gas(CH4) Measuring range 0-20 LEL%

Concentration values over 4 LEL% will trigger an 80 decibel alarm sound

4 - 8 LEL% Slight headache and fatigue(For reference only)

8 - 15 LEL% Headache and nausea(For reference only)

15 - 20 LEL% Dizziness, spasm, life threatening(For reference only)
